3dB RF DC-3GHz Attenuator 100w Coaxial Attenuator DIN Male to Female for IBS&BTS

Name: 3dB RF DC3GHz Attenuator 100w Coaxial Attenuator DIN Male to Female for IBSampBTS
Brand: HICORPWELL
Price: 1 USD

Best 3dB RF DC-3GHz Attenuator 100w Coaxial Attenuator DIN Male to Female for IBS&BTS wholesale

Brand Name : HICORPWELL

Model Number : 100w Coaxial Attenuator 3dB RF Attenuator

Certification : IEC 60794-2-10/11

Place of Origin : China

MOQ : 50 pcs

Price : negotiation

Payment Terms : Western Union, L/C, T/T

Supply Ability : 5000pcs Per Week

Packaging Details : Each piece packed in an opp bag, each opp bag packed in a small inner box,small boxes put in one standard exporting carton.450*350*340mm

Name : 100w Coaxial Attenuator 3dB RF Attenuator

Color : Black

Attenuation : 3dB/5dB/10dB/15dB/20dB/30dB/40dB/60dB

Connector Type : DIN male to female

VSWR : 1.20

Impedance(Ω) : 50 Ω

Power : 100W

Working Temperature : -55-+60 ℃

Contact Now

RF Attenuator DC-3GHz Attenuator 100w Coaxial Attenuator 3dB RF Attenuator DIN Male to Female for IBS&BTS

RF Attenuator (DC-3GHz, 100W, 4.3-10 M/F)

DC-3GHz RF Attenuator is wide frequency band(2G/3G/4G/LTE Coverage),

100W RF Attenuator is high power and widely used in IBS &DAS system.

Product Features

◆ Wide Frequency Band DC-3GHz

◆ Low VSWR

◆Low Attenuation Accuracy

◆ Widely used for In-building Solutions

Technical &Mechanical Specifications

Model No.	M-100-4MF-03	M-100-4MF-06	M-100-4MF-10	M-100-4MF-15		M-100-4MF-20	M-100-4MF-30
Freq(MHz)	DC-3GHz
Attenuation(dB)	3	6	10	15	20		30
Accuracy(dB)	±0.5	±0.5	±0.8	±1.0	±1.2		±1.5
VSWR	≤1.2
Average Power(W)	100
Impedance	50 ohm
Connector	4.3-10 M-F
Color	Black
Ambient Temp(deg)	-35~+75
Relative Humidity	5%-95%
